Manual Lens - GLM10012C

100mm f/1.2

LWIR Lens - Manual Lens



Tel:+86(0)571-88612325 Fax:+86(0)571-88612503

E-mail:info@www.quanhom.com Skype: irtekz


Optical
Focal Length 100
F/# 1.2
Average Transmission 0.88
Focus Range 5m to infinity
Detector 640X480/17µm
Field of View(FOV) 6.2ºX4.7º
M.B.F.L 18.5
Mechanical
Interface Flange
Focus Mechanism Manual
Dimensions (mm) L: 110.25 D: 96.5
Weight<590g
Electrical & Communications
Power Input NA
Communications NA
Environmental
Operating Temperature -40°C to +60°C
Storage Temperature -45°C to +70°C
External Coating DLC
Shock & Vibration MIL-E-5400/MIL-STD-810E
Front Element Sealing IP67Remark, M.B.F.L: Mechanical Back Focal Length
